CeramicSpeed BB ALPHA for BSA 30mm Road



Danish-made flagship ceramic bottom bracket for BSA English threaded frames (68mm shell) paired with 30mm axle road cranksets. Compatible with SRAM, Easton, FSA, Rotor, Cannondale, and Race Face. Grade-3 Silicon Nitride ceramic balls, hardened stainless-steel races, 500% moisture protection improvement, 80g, hand-built in Denmark with lifetime warranty.

BB ALPHA is CeramicSpeed's flagship bottom bracket line, engineered to outlast your frame. This model fits BSA English threaded frames paired with 30mm axle road cranksets, and is designed for road, triathlon, and track disciplines.

BSA (British Standard Adapter), also known as English Threaded, is the longest-standing and most widely adopted threaded bottom bracket standard in cycling. It uses a 68mm shell width with 1.370" × 24 TPI external threading. The key advantages of a threaded design include repeatable installation and removal without frame damage, no need for specialist press-fit tooling, and a lower maintenance threshold. The mechanical engagement of threads provides secure retention that is inherently resistant to the creaking issues sometimes associated with press-fit systems. The majority of traditional road frames and many modern high-end framesets continue to use BSA, making it the most broadly compatible BB standard on the market.

The bearing core uses grade-3 Silicon Nitride (Si₃N₄) ceramic balls paired with hardened stainless-steel races. The ceramic balls offer an exceptionally smooth surface and far greater hardness than steel, resulting in ultra-low friction and outstanding longevity. The hardened stainless-steel races are inherently corrosion resistant — ideal for riding in Hong Kong's hot and humid conditions where sweat and rain are constant challenges.

Protection is where BB ALPHA truly excels. Custom-engineered seals and precision dust covers were refined through 28 design iterations for optimal fitment, delivering 500% better moisture and contamination resistance than conventional designs. This dramatically extends bearing life, even through regular rain rides and bike washes.

Structurally, the cups feature optimised material and geometry for maximum strength at reduced weight, while a simplified spacer tube design uses fewer parts for quicker, more intuitive installation. Together, these changes achieve a 10% weight saving over the previous generation, bringing the net weight down to just 80g — one of the lightest threaded bottom brackets in its class. A Spacer Kit is included so riders can precisely adjust chainline position for their specific crankset brand and model.

Every BB ALPHA is hand-assembled and quality-checked at CeramicSpeed's factory in Holstebro, Denmark, and is backed by a lifetime warranty for ultimate peace of mind.

⚠️ Note: Not compatible with THM cranks.





Key Features

• Ultra-Low Friction: Grade-3 Si₃N₄ ceramic balls with hardened stainless-steel races for dramatically lower drag than steel bearings
• 500% Moisture Protection: Custom seals and dust covers refined through 28 iterations to block water and contamination from entering the bearings
• Corrosion Resistant: Hardened stainless-steel races resist rust — perfect for humid climates and sweat exposure
• Ultra Lightweight: 80g net weight — 10% lighter than the previous generation through optimised cups and spacer tube
• Threaded Installation: BSA standard threading for secure, creak-free retention with repeatable install/removal
• Broad Compatibility: Supports SRAM, Easton, FSA, Rotor, Cannondale, and Race Face 30mm cranksets
• Serviceable: Seals and dust covers are independently replaceable — no need to replace the entire unit
• Lifetime Warranty: Official CeramicSpeed lifetime warranty

In the Box

• BB ALPHA for BSA 30mm Road × 1
• Spacer Kit × 1
• UFO TECH All Round Bearing Grease 5ml × 1
• CeramicSpeed Decal × 1

Frame Compatibility

All road frames using the BSA English threaded bottom bracket standard (68mm shell width, 1.370" × 24 TPI). BSA is the most widely adopted threaded standard, found on the vast majority of traditional road frames and many modern carbon framesets.

⚠️ Before installation, confirm your frame's BB shell is 68mm BSA English threaded — not Italian threaded (70mm) or T47. If the shell is marked "1.370 × 24" or "BSA", it is compatible.

Crank Compatibility

All road cranksets with 30mm spindle, including but not limited to: SRAM Red / Force / Rival (all generations), Easton EC90 / EA90 series, FSA, Rotor ALDHU / VEGAST / 2INpower series, Cannondale Hollowgram Si / SiSL2 series, and Race Face.

⚠️ Not compatible with THM cranks. If in doubt, please check your crank specifications or contact us for confirmation.

Recommended Accessories

• CeramicSpeed Dual Socket Tool BSA/ITA (dual-sided installation tool)
